SB-15

喇叭：1*15"
Loudspeaker: 1 x 15"
Frequency Response: 38 – 200 Hz (+3 dB / -10 dB)
Power Handling: 1000 W (AES), 2000 W (Program)
Sensitivity: 97 dB
Max SPL: 130 dB (continuous), 136 dB (peak)
Nominal Impedance: 8 Ω

STAR-110P

Loudspeaker: 1 x 10" (LF), 3 x 1" (HF)
Frequency Response: 80 – 18,000 Hz (+3 dB / -10 dB)
Power Handling: 300 W (AES), 600 W (Program)
Sensitivity: 95 dB
Max SPL: 123 dB (continuous), 129 dB (peak)
Nominal Impedance: 8 Ω

STAR-110

Loudspeaker: 1 x 10" (LF), 1 x 1" (HF)
Frequency Response: 60 – 18,000 Hz (+3 dB / -10 dB)
Power Handling: 600 W (AES), 1200 W (Program)
Sensitivity: 97 dB
Max SPL: 128 dB (continuous), 134 dB (peak)
Nominal Impedance: 8 Ω

STAR-106

Loudspeaker: 1 x 6" (LF), 2 x 1" (HF)
Frequency Response: 80 – 18,000 Hz (+3 dB / -10 dB)
Power Handling: 200 W (AES), 400 W (Program)
Sensitivity: 92 dB
Max SPL: 118 dB (continuous), 124 dB (peak)
Nominal Impedance: 8 Ω

AX-126

Loudspeaker: 2 x 6.5" (LF), 1 x 1" (HF)
Frequency Response: 125 – 20,000 Hz (+3 dB / -10 dB)
Power Handling: 500 W (AES), 1000 W (Program)
Sensitivity: 94 dB
Max SPL: 124 dB (continuous), 130 dB (peak)
Nominal Impedance: 4 Ω

PX-115R

Loudspeaker: 1 x 15" (LF), 1 x 1" (HF)
Frequency Response: 55 – 20,000 Hz (+3dB / -10dB)
Power: 900W (AES), 1800W (Program)
Sensitivity: 99dB
Max SPL: 132dB (Continuous), 138dB (Peak)
Nominal Impedance: 8Ω

PX-112R

Loudspeaker: 1 × 12" (LF), 1 × 1" (HF)
Frequency Response: 60 – 20,000 Hz (+3dB / -10dB)
Power: 600W (AES), 1200W (Program)
Sensitivity: 98dB
Max SPL: 129dB (Continuous), 135dB (Peak)
Nominal Impedance: 8Ω

P-115

Loudspeaker: 1 x 15" (LF), 1 x 1" (HF)
Frequency Response: 55 – 20,000 Hz (+3dB / -10dB)
Power: 500W (AES), 1000W (Program)
Sensitivity: 98dB
Max SPL: 128dB (Continuous), 134dB (Peak)
Nominal Impedance: 8Ω

P-112

Loudspeaker: 1 x 12" (LF), 1 x 1" (HF)
Frequency Response: 65 – 20,000 Hz (+3dB / -10dB)
Power: 500W (AES), 1000W (Program)
Sensitivity: 96dB
Max SPL: 126dB (Continuous), 132dB (Peak)
Nominal Impedance: 8Ω

AX-215AS

Loudspeaker：2*15"(LF), 4*6.5"(MF), 3*1.4"(HF)
Frequency response：35 - 20,000 Hz (+3dB -10dB)
Power handling(AES)：LF 2000W, MF 1000W, HF 210W
Sensitivity：104dB
Maximum SPL：142dB(continuous), 148dB(peak)
Nominal impedance：2*8Ω(LF), 8Ω(MF), 24Ω(HF)

MULTY15ND

Loudspeker: 1 × 15" (LF), 1 × 1.4" (HF)
Frequency Response: 50 – 20,000 Hz (+3 dB / -10 dB)
Power (AES): LF 700 W, HF 70 W
Sensitivity: 100 dB
Max SPL: 133 dB (Continuous), 139 dB (Peak)
Nominal Impedance: 8 Ω

MULTY15F

Loudspeaker: 1 × 15" (LF), 1 × 1.4" (HF)
Frequency Response: 50 – 20,000 Hz (+3 dB / -10 dB)
Power (AES): LF 500 W, HF 70 W
Sensitivity: 99 dB
Max SPL: 130 dB (Continuous), 136 dB (Peak)
Nominal Impedance: 8 Ω
